1000kW Syngas Generator Set
In phrases of fuel transportation,the inlet pipe is outfitted with explosion-proof door to make sure the security of gas transportation；unit protection，overspeed，low oil pressure,over current，over pressure，high cylinder temperature，high discharge temperature，reverse electricity safety is perfect.
1000kW SYNGAS GENERATOR SET TECHNICAL SPECIFICATION
Rated power | 1000kw |
Rated voltage | 400/6300/10500 |
Rated speed | 1000rpm |
Rated frequency | 50Hz |
Type | Four stroke,water cooled,turbocharged and intercooled,spark plug ignition |
Cylinder arrangement | V style 60°included angle |
Number of cylinders | 16 |
Bore*Stroke（mm） | 200*210 |
Rated power factor | 0.8 lagging |
Voltage regulation | Automatic |
Supply connecting | 3 phase 4 wire |
Control model | EGS-02 electric governor（WOODWARD） |
Starting method | 24V DC electric starting motor |
Cooling method | Flat bed radiator or cooling tower |
After-Sale Service
1.Efficient meticulous technical services
2.Adequate spare parts
3.Round-the-clock after sale service
Packing And Delivery
1) Genset would be blanketed with plywood containers ;
2) Control panel, batteries, electric powered cables are packed with plywood bins or cartons;
3) Exhaust pipes, engine mufflers are put in the container barring packing.
