Biogas Engine Generator 700kW
Reliable 24/7 Power Availability
Cost-Effective Operation
Continuous Fuel Supply
Compact Design
The 700GF-Z biogas engine generator adopts Jichai 12V190 Engine and Domestic first-tier brands technology alternator. This gas generator set utilizes advanced control system, closed-loop electronic control technology, air-gas mixed technology before turbo-charge and lean burn technology, follows IS09001 Quality System.
700GF-Z Generator set is a proven unit which has been put into market and verified for many years, and has feature of high thermal efficiency, high load capacity and anti-load surge ability with universal parts and low maintenance cost.
Main specification of gas generator
Genset model | 700GF-Z |
Alternator model | 1FC series,siemens technology.Brushless excitation,Automatic voltage regulation. |
Panel model | GPL700 |
Rated power | 700KW |
Rated voltage | 6300V |
Rated frequency | 50HZ |
Rated power factor | 0.8 |
Wiring mood | 3 Phase 4 Wire/3 Phase 3 Wire |
Stabilized voltage regulation | ±2.5% |
Transient state voltage regulation | +20%（-15） |
Voltage stabilization time | ≤1.5s |
Fluctuation rate of voltage | ≤1% |
Stabilized frequency regulation | 0~5% |
Transient state frequency regulation | ≤±10% |
Frequency stabilized time rate | ≤7s |
Fluctuation rate of frequency | ≤0.5% |
Overall dimension | 4770mm*2040mm*2249mm |
Net weight | 14500kg |
Main specification of gas engine
Engine model | G12V190ZLZ-2 |
Type | Four strokes,Vshape，turbocharged intercooling，spark plug ignition. |
Number of cyliner | 12 |
Bore | 190mm |
Stoke | 230mm |
Total displacement | 78.3L |
Rated speed | 1000r/min |
Rated power | 550KW |
Idle speed | 770r/min |
Gas pressure | 100-300KPa 3-10KPa |
Gas consumption | ≤9500kJ/kW·h |
Oil consumption | ≤0.5g/kW·h |
Exhaust tem.(before turbine） | ≤580℃ |
Water oulet temperature | ≤90℃ |
Water inlet temperature of intercooler | <45℃ |
Oil temperature | <90℃ |
Stabilized speed droop | 0~5% |
Cooling mood | Open type-cooling tower/closed type-vertical or horizontal radiator |
Lubrication method | Pressure and splash lubrication |
Starting mood | Electric starting |
Crankshaft rotation | Counter-clockwise（face to flywheel） |
